EC500T Benchtop laboratory TDS meter conductivity meter

Parameters

Product Description

Features

* Color High contrast LCD touchscreen, 7.0 inches.
* Intelligent operation system provides features including user management, calibration management, method management, data
management and etc.
* Multi-reading feature allows auto-read, timed-read and continuous-read.
* Automatic/Manual temperature compensation ensures accurate results.
* Data Storage 1000 sets for each parameter (GLP-compliant).
* Data analysis feature helps user review, compare and recalculate results.
* Support for USB or RS-232 communication.
* Reset feature automatically resumes all settings back to factory default options.
* IP54 waterproof.
* 1-5 points calibration with Standard Recognition.
* Settable parameters, including cell constant, reference temperature (5/10/15/18/20/25°C), temperature compensation coefficient
and TDS factor.
* Temperature compensation type (none, linear, pure water).

Model			EC500T
Parameters			EC/Temp.(Resistivity/TDS/Sal.)
Conductivity	Range	0.000 μS/cm to 2000 mS/cm
		Resolution	0.001 μS/cm minimum, various with range selection
		Accuracy	±0.5% FS
		Reference Temperature	5, 10, 15, 18, 20, 25 ºC
		Calibration Points	Up to 5
		Calibration Reminder	Yes
		Standard Recognition	10 μS/cm, 84 μS/cm, 500 μS/cm, 1413 μS/cm, 12.88 mS/cm
Resistivity	Range	5.00 Ω·cm~100.00 MΩ·cm
		Resolution	0.01 Ω·cm minimum
		Accuracy	±0.5% FS
TDS	Range	0.000~1000 ppt
		Resolution	0.001 ppm minimum, changed with range
		Accuracy	±0.5%FS
Salinity	Type	NaCl%
		Range	(0.00~8.00)%
		Resolution	0.01%
		Accuracy	±0.1%
Temperature	Range	-10 to 135 ºC, 14 to 275 ºF
		Unit	ºC, ºF
		Resolution	0.1
		Accuracy	±0.1
Measurement	Reading Mode	Auto Read (Fast, Medium, Slow), Timed, Continuous
		Reading Prompts	Reading, Stable, Locked
		Temp. Compensation	ATC, MTC
Data management	Data Storage	1000 Groups
		GLP Features	Yes
		Log Management	Yes
Inputs	Conductivity with Temp. Probe	5-pin aviation connector
Outputs	USB	USB 2.0 flash memory device, PC
Outputs		RS 232	printer, scanner, auto-sampler
Display options	Backlight	Yes
		Auto Shutdown	1~60 min, off
		IP Rating	IP54
		Date and Time	Yes
General	Power	AC Adapter, 100-240V AC input, DC24V output
		Dimensions	220×195×68 mm
		Weight	950g (2.09 lb)
